| 产品型号 | LFM330Z3 | ||
| 分辨率 | 320×256（可选配640×512） | ||
| 像元间距 | 30μm | ||
| 光谱范围 | 3.2μm±0.1μm～3.5μm±0.1μm | ||
| 典型NETD | 10mK(F1.5) | ||
| 有效像元率 | ≥99.5% | ||
| 帧频 | 30Hz | ||
| 数字视频 | 标配：DVP/LVDS/USB2.0 选配：Cameralink/USB3.0/GigE/SDI/MIPI/单模光纤/多模光纤 |
||
| 通信 | 标配：USB2.0/LV-TTL 选配：RS422/CAN/USB3.0/GigE |
||
| 制冷机 | RS058I | LS713 | LS734 |
| 制冷时间(23℃) | ≤8min@12V | ≤6min30s@12V | ≤6min30s@24V |
| 稳态功耗(23℃) | ≤10W | ≤8.5W | ≤16W |
| 尺寸(mm) | ≤142×58.5×80 | ≤108×116×73 | ≤130×131×80 |
| 重量(g) | ≤680 | ≤800 | ≤1610 |
| 工作温度 | -40℃～+71℃ | ||
| 贮存温度 | -55℃～+71℃ 23mm/55mm/25-75mm |
||
| 镜头焦距 | |||
